LDH-65-1750
13.89

LDH-65-1750

$13.89

Meanwell DC-DC Step-Up Constant Current LED driver with 1750mA12.5-37VDC64.75W5%9.5~32VDC92.5%/12V 96%/24V6.2A/12VDC3.1A/24VDC

- +
Availability:In stock
SKU Meanwell LDH-65-1750
Brand Meanwell
Details

Meanwell LDH-65-1750 is 65W DC/DC LED driver with 1750mA12.5-37VDC64.75W5%9.5~32VDC92.5%/12V 96%/24V6.2A/12VDC3.1A/24VDC. It outstands constant current output. At the same time, the item could operate from 9.5~ 32VDC with rated current 1750mA. The efficiency reaches high up to 96%. Under the design of 94V-0 flame retardant plastic case, the fully-potted silicone makes it possible to fit solar LED street light enhancing the heat dissipation. In addition, LDH-65-1750 is equipped with various function options such as dimming methodologies. As a result of its long lifetime, high reliability and excellent performance, Meanwell LDH-65-1750 is an ideally suitable solution for the optimal design flexibility for DC source LED lighting system

Meanwell LDH-65-1750 price and specs DC-DC Step-Up Constant Current LED DRIVER LDH-65-700/1050/1400/1750 YCICT

Meanwell LDH-65-1750 Encoding

LDH Series Name
65 Rated Wattage
1750 Output Current ( 700/1050/1400/1750mA)
W Blank: Pin mounted Style
W: Lead Wire Style

Meanwell LDH-65-1750 Specifications

Model LDH-65-1750
OUTPUT RATED CURRENT 1750mA
CURRENT ACCURACY (Typ.) ±5% at 12VDC input and 24 VDC Input
VOLTAGE RANGE 12.5-37VDC
RATED POWER 64.75W
CURRENT RIPPLE 5%( at rated current)
Input VOLTAGE RANGE 9.5~32VDC
EFFICIENCY (Typ) 92.5%/12V 96%/24V
DC CURRENT (Typ) 6.2A/12VDC, 3.1A/24VDC
DIMMING DIMMING FUNCTION Leave open if not used
1KHz-3KHz 10V PWM signal or 0-10V DC input
QUIESCENT INPUT CURRENT
IN SHUTDOWN MODE(Typ.)
10mA when PWM dimming OFF at12VDC
PROTECTION SHORT CIRCUIT Output short circuit, the power supply will be damaged
OVER VOLTAGE 38-60V
NO LOAD Output voltage rise to OVP, and drop equal to input voltage, re-power to recovery
ENVIRONMENT WORKING TEMP. -40 ~ +60 (Refer to "Derating Curve")
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +85, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/ (0 ~ 50)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SOLDERING TEMPERATURE Wave soldering: 265,5s (max.); Manual soldering: 390,3s (max)
EMC SAFETY STANDARDS LVD BS EN/EN61347-1, BS EN/EN61347-2-13, EAC TP TC 004 approved
EMC EMISSION Compliance to BS EN/EN55015;EAC TP TC 020
EMC IMMUNITY Compliance to BS EN/EN61547,BS EN/EN61000-4-2,3,4,6,8; light industry level, EAC TP TC 020
Others MTBF 9118.4K hrs min. Telcordia TR/SR-332(Bellcore); 874.9 Khrs min. MIL-HDBK-217F (25)
DIMENSION 75*53*22.7mm (L*W*H)
PACKING Pin mounted style: 152g; 100pcs/15.2kg/0.86CUFT Lead wire style: 159g; 100pcs/15.9kg/1.07CUFT

Meanwell LDH-65-1750 Features

l  Fully encapsulated

l  3 years warranty

l  High efficiency up to 96%

l  DC/DC step-up converter

l  2 in 1dimming (0-10V, PWM)

l  Cooling by free air convection

l  Protections: Short circuit / Over voltage

l  Wide DC input voltage operation 9.5~32V

l  Constant current output: 700mA to 1750mA

l  Wide output LED forward voltage up to 80V DC

Meanwell LDH-65-1750 Applications

l  DC battery source lighting

l  Portable lighting

l  LED solar street lighting

l  LED greehouse lighting

l  LED Low-bay lighting

Meanwell LDH-65-1750 Mechanical Diagram

Meanwell LDH-65-1750 price and specs 65w DC-DC Step-Up Constant Current LED DRIVER LDH-65-700/1050/1400/1750 YCICT

Meanwell LDH-65-1750 price and specs 65w DC-DC Step-Up Constant Current LED DRIVER LDH-65-700/1050/1400/1750 YCICT
