HEP-480-36
190.28

HEP-480-36

$190.28

Meanwell 480W Switching Power Supply for Harsh Environment with 36V13.3A478.8W250mVp-p±1.0%±0.5%±0.5%

- +
Availability:In stock
SKU Meanwell HEP-480-36
Brand Meanwell
Details

Meanwell HEP-480-36 is a 480W industrial AC/DC power supply with 36V13.3A478.8W250mVp-p. The model outstands the powerful capability to work under highly humid, dusty, oily, and high-vibration harsh conditions. HEP-480-36 is also housed with the aluminum case and fully potted with heat-conducted silicone. As per the state-of-the-art design, the working efficiency could reach up to 95%, which assures to perfectly work between -55℃ and +65℃ under free air convection. Furthermore, HEP-480-36 Is able to meet 6KV surge immunity level and withstand 10G vibration test. What’s more, it provides the full protection functions such as Short circuit, Overload, Over voltage and Over temperature. In view of the high efficiency, high reliability and long longevity, Meanwell HEP-480-36 is a high performance solution for various industrial applications.

Meanwell HEP-480-36 Mechanical Diagram

Meanwell HEP-480-36 Encoding

HEP Series Name
480 Output  Wattage
36 Output Voltage
A Function Mode Option A : Standard model, IP65, Vo and Io level can be adjusted through internal potentiometer.
Blank : Optional model, IP68, with fixed Vo and lo level.

Meanwell HEP-480-36 Specifications

Model HEP-480-36
OUTPUT DC VOLTAGE 36V
RATED CURRENT 13.3A
RATED POWER 478.8W
RIPPLE & NOISE (max.) 250mVp-p
VOLTAGE TOL ERANCE  ±1.0%
LINE REGULATION ±0.5%
LOAD REGUL .ATION ±0.5%
SETUP, RISE TIME 500ms, 80ms 115VAC/230VAC
HOLD UP TIME (Typ.) 16ms 115VAC/230VAC
VOLTAGE RANGE 85~264VAC (277VAC operational) 120~370VDC(390VDC operational)
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF>0.98/115VAC, PF>0.97/230VAC, PF>0.95/277VAC at full load
EFFICIENCY (Typ.) 94.00%
INPUT AC CURRENT (Typ.) 5A / 115VAC 2.45A / 230VAC 2A/277VAC
INRUSH CURRENT(Typ.) COLD START 35A at 230VAC
LEAKAGE CURRENT <0.75mA / 277VAC
OVER LOAD 105 ~ 125%
Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE 40-50V
PROTECTION Shut down output voltage, re-power on to recover
OVER TEMPERATURE Shut down output voltage, re-power on to recover
WORKING TEMP. -55 ~ +65 (Refer to "Derating Curve")
WORKING HUMIDITY 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -60 ~ +80, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT ±0.03%/(0 ~ 60)
ENVIRONMENT VIBRATION 20 ~ 500Hz, 10G 12min./1cycle, period for 72min. each along X, Y, Z axes
SAFETY STANDARDS Note.6,9 UL62368-1,IEC62368-1, IP65 (or IP68 for HEP-480 Blank-Type), EAC TP TC 004 approved ;Design refer to BS EN/EN62368-1
WITHSTAND VOLTAGE I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH
EMC EMISSION Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
SAFETY & EMC SAFETY STANDARDS Note.6,9 UL62368-1,IEC62368-1, IP65 (or IP68 for HEP-480 Blank-Type), EAC TP TC 004 approved ;Design refer to BS EN/EN62368-1
WITHSTAND VOLTAGE I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH
EMC EMISSION Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC IMMUNITY Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55024, light industry level (surge 6KV), criteria A, EAC TP TC 020
OTHERS MTBF 89.8K hrs min. MIL-HDBK-217F (25)
DIMENSION 262*125*43.8mm (L*W*H)
PACKING 2.8Kg;4pcs/11.5Kg/0.55CUFT

Meanwell HEP-480-36 Features

l  6 years warranty

l  Built-in active PFC function

l  High efficiency up to 95%

l  Meet 6KV surge immunity level

l  Withstand 10G vibration test

l  -55℃~+65 ℃ wide operating range

l  Operating altitude up to 5000 meters

l  Fanless design, cooling by free air convection

l  Aluminum case and filling with heat-conducted silicone

l  IP65 design, optional IP68 rated model available

l  Universal AC input/Full range (up to 305VAC)

l  Protections: Short circuit/Overload/Over voltage/Over temperature

Meanwell HEP-480-36 Features

Meanwell HEP-480-36 Applications

l  Petroleum plant or mine shaft facility

l  Outdoor telecommunication equipment

l  Outdoor electronic signage and billboard

Meanwell HEP-480-36 Applications

Meanwell HEP-480-36 Mechanical Diagram

Meanwell HEP-480-36 Mechanical DiagramMeanwell HEP-480-36 Mechanical Diagram

Meanwell HEP-480-36 Mechanical Diagram
