ELG-240-C700
38.14

ELG-240-C700

$38.14

Meanwell 178.5~240W Constant Current Mode LED Driver with 700mA200VAC~305VAC240.1W100VAC~180VAC179.9W171.343V360V350-700mA±5.0%

- +
Availability:In stock
SKU Meanwell ELG-240-C700
Brand Meanwell
Details

Meanwell ELG-240-C700 is a 240W LED AC/DC driver with 700mA200VAC~305VAC240.1W100VAC~180VAC179.9W171.343V360V350-700mA. The product features the constant current mode and high voltage output. Meanwhile, it is able to operate from 100~ 305VAC and offered with the rated current 700mA. Since the high efficiency reaches up to 93% under the fanless design, ELG-240-C700 could work for -40℃ + 85℃ case temperature with free air convection. What’s more, the metal housing design and IP67/IP65 ingress protection level permit it to meet with both indoor and outdoor applications. Besides them, the unit is equipped with various function options such as dimming methodologies. Thanks to its long lifetime, high efficiency and excellent performance, Meanwell ELG-240-C700 is an ideally suitable solution for the optimal design flexibility for LED lighting system.

Meanwell ELG-240-C700 Meanwell ELG-240-C series price and specs 240W LED AC/DC driver ycict

Meanwell ELG-240-C700 Encoding

ELG Series Name
240 Rated Wattage
C700 Rated Output Current (700/1050/1400/1750/2100mA)
A Function Option
***( Input Wiring Type) Blank: 2-wire input for standard model)
3Y: 3-wire input for standard model)
Type IP Level Function Note
Blank IP67 IO  fixed In stock
A IP65 lo adjustable through built-in potentiometer. In stock
IP67 3 in 1 dimming function (0~ 10Vdc, 10V PWM signal and resistance) In stock
AB IP65 lo adjustable through built-in potentiometer &
3 in 1 dimming function (0~ 10Vdc, 10V PWM signal and resistance)
In stock
DA IP67 DALI control technology In stock
Dx IP67 Built-in Smart timer dimming function by user request By request
D2 IP67 Built-in Smart timer dimming and programmable function In stock

Meanwell ELG-240-C700 Specifications

Model ELG-240-C700
Output RATED CURRENT 700mA
RATED POWER 200VAC ~ 305VAC
240.1W
100VAC ~ 180VAC
179.9W
CONSTANT CURRENT REGION 171.343V
OPEN CIRCUIT VOLTAGE 360V
CURRENT ADJ. RANGE Adjustable for A/AB-Type only (via built-in potentiometer)
350-700mA
CURRENT RIPPLE 5.0% max.  At rated current
CURRENT TOLERANCE ±5.0%
SET UP TIME 800ms/115VAC, 500ms/230VAC
Input VOLTAGE RANGE 100 ~ 305VAC 142 ~ 431VDC
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF>=0.97/115VAC, PF>=0.95/230VAC, PF>=0.92/277VAC at full load
TOTAL HARMONIC DISTORTION THD< 20%( at load>=50%/115VC,230VAC; at load>=75%/277VAC)
EFFICIENCY (Typ.)  93.00%
AC CURRENT (Typ.) 2.2A / 115VAC 1.5A / 230VAC 1.2A/277VAC
INRUSH CURRENT (Typ. ) COLD START 75A(twidth=450μs measured at 50% Ipeak)/230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER 2 units (circuit breaker of type B) / 4 units (circuit breaker of type C) at 230VAC
NO LOAD / STANDBY POWER CONSUMPTION No load power consumption <0.5W for Blank / A / Dx / D2-Type
Standby power consumption <0.5W for B / AB / DA-Type
LEAKAGE CURR ENT <0.75mA / 277VAC
PROTECTION SHORT CIRCUIT Hiccup mode, recovers automatically after fault condition is removed
OVER TEMPERATURE Shut down o/p voltage, re-power on to recover
OVER VOLTAGE 380-435V
Shut down o/p voltage, re-power on to recover
ENVIRONMENT WORKING TEMP Tcase=-40 ~ +85 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
MAX. CASE TEMP. Tcase=+85
WORKING HUMIDITY 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +80, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/ (0 ~ 60)
VIBRATION 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
SAFETY &EMC SAFETY STANDARDS UL8750(type”HL”), CSA C22.2 No. 250.13-12;BS EN/EN/AS/NZS 61347-1,BS EN/EN/AS/NZS 61347-2-13
independent, BS EN/EN62384; GB19510.14,GB19510.1;BIS IS15885(for 700A/1050A only);IP65 or IP67;
KC61347-1,KC61347-2-13 approved
DALI STANDARDS Compliance to IEC62386-101,102,(207 by request) for DA Type only
WITHSTAND VOLTAGE I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH
EMC EMISSION Compliance to BS EN/EN55015,BS EN/EN61000-3-2 Class C (at load>=50%) ; BS EN/EN61000-3-3;
GB17625.1, GB17743; EAC TP TC 020; KC KN15,KN61547
EMC IMMUNITY Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level(surge immunity:
Line-Earth:6KV,Line-Line:4KV);EAC TP TC 020; KC KN15,KN61547
Others MTBF 2730.9K hrs min. Telcordia SR-332 (Bellcore) ; 235K hrs min. MIL-HDBK-217F (25)
DIMENSION 244*71*37.5 mm (L*W*H)
PACKING 1.22Kg; 12pcs /15.2kg / 0.72CUFT

Meanwell ELG-240-C700 Features

l  Typical life time>50000 hours

l  5 years warranty

l  Constant Current mode output

l  Metal housing design with functional Ground

l  Built-in active PFC function

l  No load/Standby power consumption<0. 5W

l  IP67/IP65 rating for indoor or outdoor installations. Function options: output adjustable via potentiometer; 3 in 1 dimming (dim-to-off); Smart timer dimming; DALI

Meanwell ELG-240-C700 Features Meanwell ELG-240-C700 price and specs 240w ac dc led driver ycict

Meanwell ELG-240-C700 Features

l  L ED street lighting

l  LED harbor lighting

l  LED bay lighting

l  LED greenhouse lighting

l  LED flood lighting

l  Type HL" for use in Class l, Division 2 hazardous (Classified) location

Meanwell ELG-240-C700 Mechanical Diagram

Meanwell ELG-240-C700 Mechanical Diagram Meanwell ELG-240-C700 price and specs 240w ac dc led driver ycict

Meanwell ELG-240-C700 Mechanical Diagram Meanwell ELG-240-C700 price and specs led driver good price ycict
