MPM-10-15

$9.41

Meanwell 10W High Rel iable Green Medical Encapsulated Type with 15V0.67A0-0.67A0.74A10W11.1W180mVp-p±2.5%±0.3%±0.5%

- +
Availability:In stock
SKU Meanwell MPM-10-15
Brand Meanwell
Details

Meanwell MPM- 10-15 is a 10W AC/DC module type medical grade power supply with 15V0.67A0-0.67A0.74A10W11.1W180mVp-p. the product is designed in high density and small size with pin type. It operates for 80~ 264VAC with low no load power consumption < 0.075W, and high efficiency reaching up to 84%. At the same time, MPM-10-15 provides the interior potting, 5G anti-vibration, high EMC performance and 4KV AC isolation, etc, this allows to meet the regulations such as IEC/BS EN/EN60601-1 and ANSI/AAMI ES60601-1version three with 2xMOPP level. Additionally, the unit offers Class II (no FG) double insulation, outstanding dissipation and ultra-low leakage current. In view of its longevity, high reliability, excellent quality, Meanwell MPM- 10-15 is a very suitable solution for BF (patient contact) type medical device or relevant equipment.

Meanwell MPM-10-15 Encoding

Meanwell MPM-10-15 Encoding

MPM Series Name
10 Rated Wattage
15 Output Voltage

Meanwell MPM-10-15 Specifications

Model MPM-10-15
OUTPUT DC VOLTAGE 15V
RATED CURRENT 0.67A
CURRENT RANGE 0-0.67A
PEAK CURRENT 0.74A
RATED POWER 10W
PEAK LOAD(10sec.) 11.1W
RIPPLE & NOISE (max.) 180mVp-p
VOLTAGE TOL ERANCE  ±2.5%
LINE REGULATION ±0.3%
LOAD REGUL .ATION ±0.5%
SETUP, RISE TIME 1000ms, 30ms/230VAC 1000ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.) 40ms/230VAC 8ms/115VAC at full load
INPUT VOLTAGE RANGE 80 ~ 264VAC
FREQUENCY RANGE 47 ~ 440Hz
EFFICIENCY (Typ.) 83%
AC CURRENT (Typ.) 0.3A/115VAC 0.2A/230VAC
INRUSH CURRENT(Typ.) COLD START 25A/115VAC 45A/230VAC
LEAKAGE CURRENT Touch current <80μA/264VAC
PROTECTION OVERL OAD 110% ~ 180% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE 17.3-20.3V
Protection type : Shut off o/p voltage, clamping by zener diode
OVER TEMPERATURE Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
ENVIRONMENT WORKING TEMP. -30 ~ +85(Refer to "Derating Curve")
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +100, 10 ~ 95% RH non-condensing
TEMP. COEFFICIENT ±0.03%/(0 ~ 50)
SOLDERING TEMPERATURE 260±5/10sec.max.
VIBRATION 10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes
LEAD TEMPERATURE 260±5,5s (max.)
OPERATING ALTITUDE 5000 meters
SAFETY & EMC SAFETY STANDARDS Note.6,9 IEC60601-1, BS EN/EN60601-1, , UL ANSI/AAMI ES60601-1(3.1 version), CAN/CSA-C22 3 Edition approved ; rd EAC TP TC 004 Design refer to BS EN/EN60335-1(by request)
ISOLATION LEVEL Primary-Secondary: 2xMOPP
WITHSTAND VOLTAGE I/P-O/P:4KVAC
ISOLATION RESISTANCE I/P-O/P:100M Ohms / 500VDC / 25/ 70% R
EMC IMMUNITY BS EN/EN60601-1-2
OTHERS MTBF 1756.2Khrs min. MIL-HDBK-217F (25)
DIMENSION 45.7*25.4*21.5mm (L*W*H) or 1.8*1.0"0.85" inch
PACKING 0.035Kg; 270pcs/10.5Kg/0.94CUFT

Meanwell MPM-10-15 Features

l  3 years warranty

l  1.8"x1" compact size

l  No minimum load required

l  Extremely low leakage current

l  EMI class B for class I configuration

l  No load power consumption<0.07 5W

l  Wide operating temp. range -30 ~ +85℃

l  Suitable for BF application with appropriate system consideration

l  Protections: Short circuit/Overload/Over voltage/Over temperature

l  Medical safety approved (2 X MOPP) according to ANSI/AAMI ES60601-1 and IEC/BS EN/EN60601-1

Meanwell MPM-10-15 Features

Meanwell MPM-10-15 Applications

l  Portable medical device

l  Mobile clinical workstation

l  Medical computer monitor

l  Medical examination instrument

Meanwell MPM-10-15 Applications

Meanwell MPM-10-15 Mechanical Diagram

Meanwell MPM-10-15 Mechanical DiagramMeanwell MPM-10-15 Mechanical Diagram
