LPF-60-36
21.85

LPF-60-36

$21.85

Meanwell 60W Constant Voltage + Constant Current LED Driver with 36V21.6-36V1.67A60.12W250mVp-p±4.0%±0.5%±0.5%

- +
Availability:In stock
SKU Meanwell LPF-60-36
Brand Meanwell
Details

Meanwell LPF-60-36 is 60W AC/DC LED driver with 36V21.6-36V1.67A60.12W250mVp-p±4.0%±0.5%±0.5%. The unit stands out with the dual modes constant voltage and constant current output. And it could work from 90~ 305VAC, offering the model with rated voltage 36V. As the high efficiency reaches up to 90% based on fanless design, LPF-60-36 is able to operate for -40°C ~ +80°C case temperature via free air convection. What’s more, it is rated with IP67 ingress protection level. In light of its longevity, high reliability and excellent quality, Meanwell LPF-60-36 is suitable to work for a variety of applications at dry, damp or wet locations.

Meanwell LPF-60-36 price and specs 60W Constant Voltage and Constant Current AC/DC LED driver PFC IP67 level YCICT

Meanwell LPF-60-36 Encoding

LPF Series Name
60 Rated Wattage
36 Rated output voltage (12V/15V/20/24V/30V/36V/42V/48V/54V)

Meanwell LPF-60-36 Specifications

Model LPF-60-36
OUTPUT DC VOLTAGE 36V
CONSTANT CURRENT REGION 21.6-36V
RATED CURRENT 1.67A
RATED POWER 60.12W
RIPPLE & NOISE (max.) 250mVp-p
VOLTAGE TOL ERANCE ±4.0%
LINE REGULATION ±0.5%
LOAD REGULATION ±0.5%
SETUP, RISE TIME 1000ms, 80ms / 115VAC 500ms, 80ms / 230VAC
HOLD UP TIME (Typ.) 16ms/230VAC 16ms/115VAC
Input VOLTAGE RANGE 90~305VAC 127~431VDC (Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR PF>=0.97/115VAC, PF>=0.95/230VAC, PF>=0.92/277VAC at full load (Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION THD< 20% (at load>=60%/115VC,230VAC; at load>=75%/277VAC) (Please refer to“TOTAL HARMONIC DISTORTION(THD)”section)
EFFICIENCY (Typ.) 90.00%
AC CURRENT 0.8A / 115VAC 0.4A / 230VAC 0.32A/277VAC
INRUSH CURRENT(Typ.) COLD START 55A (twidth=270μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER 8 units (circuit breaker of type B) / 14 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT <0.75mA / 240VAC
PROTECTION OVER CURRENT 95 ~ 108%
Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE 41-49V
Shut down and latch off o/p voltage, re-power on to recover
OVER TEMPERATURE Shut down o/p voltage, re-power on to recover
ENVIRONMENT WORKING TEMP. Tcase=-40 ~ +80 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
MAX. CASE TEMP. Tcase=+80
WORKING HUMIDITY 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +80, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/ (0 ~ 50)
VIBRATION 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
SAFETY & EMC SAFETY STANDARDS UL8750, CSA C22.2 No. 250.0-08, ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, IP67, J61347-1, J61347-2-13, BIS IS15885(for 24V only), EAC TP TC 004,GB19510.1,GB19510.14 approved ; design refer to UL60950-1
WITHSTAND VOLTAGE I/P-O/P:3.75KVAC
ISOLATION RESISTANCE I/P-O/P:100M Ohms / 500VDC / 25/ 70% RH
EMC EMISSION Compliance to BS EN/EN55015,BS EN/EN61000-3-2 Class C (at load>=60%) ; BS EN/EN61000-3-3,
GB17743 and GB17625.1, EAC TP TC 020
EMC IMMUNITY Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level (surge immunity Line-Line 2KV), EAC TP TC 020
Others MTBF 3786.9K hrs min. Telcordia SR-332 (Bellcore) ; 440.6Khrs min. MIL-HDBK-217F (25)
DIMENSION 162.5*43*32mm (L*W*H)
PACKING 0.45Kg; 32pcs/15.4Kg/0.93CUFT

Meanwell LPF-60-36 Features

l  5 years warranty

l  Class 2 power unit

l  Built-in active PFC function

l  Typical lifetime> 50000 hours

l  Plastic housing with Class Il design

l  Fully encapsulated with IP67 level

l  Constant Voltage + Constant Current mode output

Meanwell LPF-60-36 price and specs 60W Constant Voltage and Constant Current AC/DC LED driver with PFC IP67 level YCICT

Meanwell LPF-60-36 Applications

l  Moving sign

l  LED downlight

l  LED panel lighting

l  LED tunnel lighting

l  LED decorative lighting

Meanwell LPF-60-36 Mechanical Diagram

Meanwell LPF-60-36 price and specs 60W Constant Voltage and Constant Current AC/DC LED driver PFC IP67 level YCICT

Meanwell LPF-60-36 price and datasheet 60W Constant Voltage and Constant Current AC/DC LED driver PFC IP67 level YCICT
